Flexit ProNordic L230R is a high-capacity commercial air handling unit from the Norwegian ProNordic range — designed for larger office buildings, schools, retail centres, fitness facilities and apartment complexes. With a maximum airflow of up to 2 950 m³/h (at 250 Pa, SFP 2.0) and a circular side duct connection of Ø500 mm, it covers spaces with high ventilation demands while retaining the installation flexibility characteristic of the L-series. Powered by high-efficiency EC fans (2×750 W) and a rotary heat exchanger, the unit achieves annual heat recovery efficiency of >86 % at SFP 1.5. The Siemens Climatix CS2500 control system with Modbus communication ensures straightforward integration into building management systems (BMS). Supplied as a right-hand variant with 400 V configuration, easily convertible to left-hand and 230 V directly on site — making it impossible to order the wrong variant.
Key Benefits
Performance Parameters
Flexit ProNordic L230R delivers an airflow of up to 2 950 m³/h at 250 Pa (SFP 2.0 / 83 %). At a lower setting (SFP 1.5), it achieves 1 950 m³/h at 250 Pa with higher heat recovery efficiency (>86 %). The circular side duct connection Ø500 mm allows optimal duct routing even in space-constrained installations.
@ 250 Pa (SFP 2.0 / 83 %)
@ 250 Pa (SFP 1.5 / 86 %)
(circular, side-mounted)
(SFP 1.5 / 1 950 m³/h)
Siemens Climatix CS2500 control system
Integrated control system with constant airflow or 3-speed regulation. Modbus TCP/IP or RTU communication for connection to building management systems (BMS). ProPanel (push-button) or ProTouch (touch-screen display, Android) control panel available as an accessory. Optional BACnet IP module for extended integration into various BMS platforms.
Flexible design — impossible to order wrong
Supplied as a right-hand variant with 3N~400 V configuration. Conversion to left-hand and 230 V is done directly on site. The heating coil (electric 10 800 W or water-based) is installed on site. This flexibility eliminates the risk of ordering the wrong variant and saves costs when project changes occur. The unit is kept in stock at Flexit with standard lead times.
Larger commercial buildings — offices, schools, logistics
With an airflow of up to 2 950 m³/h, ProNordic L230R is ideal for ventilating larger office buildings, school campuses, shopping centres, fitness centres, hospitals and logistics facilities. The side connection Ø500 mm opens installation possibilities even where top duct connection is not feasible.
Robust construction — Nordic Swan Ecolabel
Double-walled panels with thermal insulation and no thermal bridges ensure excellent thermal efficiency. High-quality bag ePM1 55 % (F7) filtration on both supply and extract air captures fine dust and pollen. 5-year manufacturer warranty.
Easy installation and servicing
ProNordic L230R is designed with a focus on efficient installation and maintenance. All air connections are located on the side of the unit (circular connection Ø500 mm), enabling optimal duct connection even in rooms with limited ceiling height or overhead obstructions.
The unit can be disassembled into individual modules — rotor module (75 kg), fans (2×15 kg) and doors (4×17 kg) — reducing the net weight for transport to 177 kg. Overall dimensions of 1 830×1 430×1 335 mm require adequate access to the technical room.
Automatic bypass provides free cooling during transitional periods. Filter alarm based on pressure differential alerts when filter replacement is needed.
ProPanel and ProTouch — two control options
ProPanel is a standard push-button control panel for basic operation and unit status overview. Suitable where simple control without advanced settings is sufficient.
ProTouch is a Siemens touch-screen panel (Android) with an application for local connection to the unit. It offers extended settings, visualisation of operating parameters and alarm history. Both panels are supplied separately as accessories.
Technical Specifications
| Parameter | Value |
|---|---|
| Max. airflow (SFP 2.0 / 83 %) | 2 950 m³/h @ 250 Pa |
| Airflow (SFP 1.5 / 86 %) | 1 950 m³/h @ 250 Pa |
| Heat recovery efficiency | >83 % at 2 950 m³/h; >86 % at 1 950 m³/h |
| Heat exchanger type | Rotary (regenerative) |
| Fan type | B-wheel radial with EC motors |
| Fan power | 2×750 W (230 V) |
| Rotor motor power | 40 W |
| Max. fan speed | 3 000 rpm |
| Electric heating coil (optional) | 10 800 W |
| Water heating coil | Optional (on-site installation) |
| Rated voltage (standard) | 3N~400 V / 50 Hz (convertible to 230 V) |
| Total power (with electric coil, 400 V) | 12 510 W |
| Total power (with water coil, 400 V) | 1 710 W |
| Rated current (electric coil, 400 V) | 19.8 A |
| Fuse rating (electric coil, 400 V) | 3×25 A |
| Rated current (water coil, 400 V) | 4.2 A |
| Fuse rating (water coil, 400 V) | 3×10 A |
| Duct connection | Ø500 mm (circular, side-mounted) |
| Filters | Bag ePM1 55 % (F7), 550×500×400 mm |
| Control system | Siemens Climatix CS2500 |
| Communication | Modbus TCP/IP or RTU |
| Fan regulation | ModBus (constant airflow / 3 speeds) |
| Dimensions (W×H×D) | 1 830×1 430×1 335 mm |
| Depth without doors | 1 100 mm |
| Gross weight | 350 kg |
| Net weight (transport) | 177 kg |
| Rotor module weight | 75 kg |
| Fan weight | 2×15 kg |
| Door weight | 4×17 kg |
| Operating temperature | −30 °C to +40 °C |
| Configuration | Right-hand (convertible to left-hand on site) |
| Installation | Floor-mounted, technical room |
| Control panels | ProPanel (push-button) / ProTouch (touch-screen, Siemens Android) |
| Certifications | Nordic Swan Ecolabel eligible |
| Product no. | 152600 |
| GTIN | 7023671526009 |
ProNordic L230R vs L190R vs L350R — which model to choose?
ProNordic L230R — max. 2 950 m³/h at 250 Pa. Side circular connection Ø500 mm — suited for larger spaces and installations without top duct connection. Dimensions 1 830×1 430×1 335 mm, weight 350 kg (net 177 kg). Ideal for office buildings, schools and logistics facilities.
ProNordic L190R — max. 2 650 m³/h at 200 Pa. Side circular connection Ø400 mm — more compact option for smaller spaces with side duct runs. Lighter (net 128 kg), fits through a 90 cm doorway. Suited for retail spaces and medium-sized office buildings.
For the largest projects, consider ProNordic L350R (up to 5 850 m³/h, side rectangular connection 1 200×600 mm). For residential use (family homes), we recommend the Flexit Nordic range — models Nordic S4 (461 m³/h) or Nordic L6 SW (657 m³/h).
High-capacity commercial ventilation. Side connection Ø500 mm. Professional control.
Flexit ProNordic L230R is an energy-efficient air handling unit with a rotary heat exchanger, airflow of up to 2 950 m³/h, circular side connection Ø500 mm and Siemens Climatix CS2500 control — powerful, flexible and in stock.
